Deskripsi
Technical data
| Atex Certification : | STANDARD : II 3G Ex h IIB T4 Gc – II 3D Ex h IIIB 135°C Dc
CONDUCT : II 2/2 G/D Ex h IIC T4 Gb/Db – I M2 Ex h Mb |
| Construction Material : | ALUMINUM, AISI 316 |
| Intake/delivery connections : | G2” – DN 50 (on request) |
| Air connection : | 3/4” |
| Max. flow rate : | 696 L/min |
| Max. flow pressure : | 7 bar |
| Operating pressure : | Min. 2 bar – Max.7 bar |
| Max. suction head : | 5 m |
| Max. size of solids : | 8.0 mm |
| Max. operating Temperature : | Aluminum 95⁰C , AISI316 95⁰C |
| Weight Aluminum : | 35.0 Kg |
| Weight AISI316 : | 64.0 Kg |
