Deskripsi
Technical data
| Atex Certification : | STANDARD : II 3G Ex h IIB T4 Gc – II 3D Ex h IIIB 135°C Dc
CONDUCT : II 2/2 G/D Ex h IIC T4 Gb/Db – I M2 Ex h Mb |
| Construction Material : | PP, PVDF+CF, PP+CF, Aluminum , AISI316 |
| Intake/delivery connections : | 1 ” BSP F |
| Air connection : | 1/2” |
| Max. flow rate : | 185 L/min |
| Max. flow pressure : | 8 bar |
| Operating pressure : | Min. 2 bar – Max.8 bar |
| Max. suction head : | 4 m |
| Max size of solids : | 3.5 mm |
| Max. operating Temperature : | PP: 60⁰C, PP+CF:60⁰C, PVDF+CF: 95⁰C, ALU-AISI316 : 95⁰C, ALU-AISI 316 w/center block: 130⁰C |
| Weight : | PP: 6 Kg, PVDF+CF: 7 Kg, ALU: 8 Kg , AISI316 : 14Kg |
