Deskripsi
Technical data
|
Construction Material : |
Body : AISI 316 // Aluminum
Rotors : AISI316 O-rings : PTFE , FKM , NBR |
| Port Size : | 1/4” BSP (F) |
| Flow rate : | 15 ~ 550 L/hr // 4 ~ 134 US gal |
| Pressure ratings : | AISI316 : 34 Bar // 500 Psi
Aluminum: 15 Bar // 220 Psi |
| Max Temperature : | 150°C |
| Max. Viscosity : | 1,000,000 Cps |
| Accuracy : | ± 1 % |
| Repeatability : | ± 0.03 % |
| Output pulse resolution: | Reed switch 355 Pulse / Lt, 1345 Pulse / US Gallon
Hall effect : 710 Pulse / Lt , 2690 Pulse / US Gallon |
| Available digital displays : | AMR100 , F012 , F110 |
| Available Batch controllers : | F030 , F130 |
Benefits
- Measurement according to the oval gear principle
- For very small flow rates
- For thin-bodied up to viscous liquids
- Low friction resistance
- Very precise dosing possible
- High resistance
- Wide range of viscosities can be covered
- Can also be used for pulsating volume flows
- Low pressure loss
